Zinc Selenide is the most popular material for infrared applications in high power CO₂ lasers.   Our CVD ZnSe grown with special grain size control technique is very stable under thermal shock and harsh environment. It has transmission range from 0.5 to18μm and very low absorption at 10.6μm with the bulk absorption coefficient less than 5×10^-4cm^-1.

ZnSe Optics and Blanks

Specification:
Tolerance
             Diameter:               +/- 0.05mm
             Length & Width:    +/- 0.05 ~ +/-0.1mm
             Thickness:              +/- 0.05mm
             Flatness                N<2
             Parallelism              <2'
             Bevel                    0.2 ~ 1mm
             Edge.Chips            =0.5mm
             ETV                       =0.05mm
             Surface                  40/20 or 60/40

 We can also make with custom specifications if required.

· Windows (coated and uncoated)

· Lenses (coated and uncoated)

· Prisms (coated and uncoated)

· Polished and unpolished blanks:

       Plano round blanks
       Curve generated blanks
       Rectangular and old shapes



Anti-reflection Coating

We offer Anti-reflection coating on ZnSe components.

                            ZnSe AR Coated Windows 10.6 µm                TAVG>98%

Ge and ZnSe window blanks
